Dimensions:
5.5” H x 5.5” W x 2.25” D
|
|
Ambient conditions:
Indoor use only, 32 to 122°F (0 to 50°C), RH ≤90% Noncondensing
|
|
Approvals:
CSA C US, meets class B: ICES & FCC Part 15
|
|
Enclosure:
Blue PC+ABS plastic, NEMA type 1
|
|
Control:
Microprocessor control. This is not a safety (limit) control
|
|
Warranty:
Limited 3 Year (See D313 for full warranty)
|
|
Sensors:
NTC thermistor, 10 kΩ @ 77°F (25°C ±0.2°C) ß=3892
|
|
Packaged weight:
1.4 lb
|
|
Power supply:
24 V (ac) ±10%, 60 Hz, 3 VA min, 99 VA max, Class 2
|
|
Zone valve load:
24 V (ac) 2 A, maximum combined current (zones 1 to 4): 4 A
|
|
End switch relay:
24 V (ac) 2 A
|
|
Zone group pump:
115 V (ac) 5 A
|
|
–Included Sensors:
None
|
|
-Optional Sensors:
Outdoor Sensor 070
|
