| Voltage (VAC/Hz/Phase) | 240 VAC / 60 Hz / 1 Phase |
| Power (kW) | 12 |
| Heat Output (BTU/hr) | 40944 |
| Current Load (Amps) | 50 |
| Elements (kw) | 2 x 6 kW |
| Stages | 2 |
| Electrical Supply (Awg) | 6 Cu, 4 Al |
| Breaker (Amp) | 70 Amp |
| DHW Production in 10 min (Gal) | 18 |
| DHW Production in 1 hr (Gal) | 11 |
